Zenergize AC chargers offer power options from 7.4kW to 22kW with advanced features like auto-resume after power cuts, grid-adjustable current, and localized user interfaces. Fully compliant with global standards, these chargers ensure seamless integration, easy configuration, and reliable performance, making them ideal for both home and public use.
| Parameters | Rated Capacity | 22 kW Dual Gun |
|---|---|---|
| Input Parameters | Input Voltage Range | 350-460 V (l-l) |
| Input Frequency Range | 45 – 65 Hz | |
| Maximum Input Current | 32 A rms per phase | |
| Input Voltage Type | Three Phase, 5 Wire (R,Y,B, N, PE) | |
| Power Output | Output Voltage | Same as input voltage |
| Output Current per gun | Max. 16 A rms per phase | |
| Standard / Connector | Type-2 AC | |
| No. of Connectors / Guns | 2 | |
| Protection & Safety | Safety Parameters | Input Over Voltage, Input Under Voltage, Over Current, Short Circuit, Surge Protection, Over Temperature, Residual Current Protection, Emergency Shut-down with alarm |
| Interface and Control Functions | Display Screen | 3.5 inch touch screen HMI (optional) |
| Languages Supported | English | |
| Push Button | Emergency Stop | |
| Visual Indication | Presence of Input Supply, Error Indicator | |
| User Authentication | Mobile Application, QR Code,RFID Card, Password Login | |
| Communication | Between EV Charger and EV | Low Level Communication as per IEC 61851-1 |
| Between EV and Central Server | OCPP 1.6J/OCPP 2.0.1 software protocol via Wifi or GSM Modem (2G/3G/4G) or Ethernet (optional) | |
| Mechanical | Protection | IP 54 |
| Cooling | Natural Air Cooling | |
| Charging Cable Length | 5m | |
| Operating Temperature | -25 ° C to 55 ° C | |
| Storage Temperature | -25° C to 55 ° C | |
| Humidity | 5% to 95% | |
| Weight | Less than 12 kgs | |
| Dimensions (mm) | 350 (H) x 450 (W) x 120 (D) all in mm |
